8 x 75mm Multifix Concrete Bolts Hex

€29.00

8 x 75mm Multifix Concrete Bolts are ready for next day delivery or collect in Sandyford, Co.Dublin.

Hex head concrete bolt
Can be removed easily
Heavy duty anchor for concrete, brick, stone
100 per box

In stock

SKU MF875 Category

Description

8 x 75mm Multifix Concrete Bolts are ready for next day delivery or collect in Sandyford, Co.Dublin.

8 x 75mm Multifix Concrete Bolts Hex head is a stress free, non-expansion through fixing is the new solution for heavy duty anchoring into concrete, brick, stone, wood and concrete block replacing the need for traditional anchors such as throughbolts, shield, sleeve and drop-in anchors.

The Multi-Fix Masonry Bolts – Hex Flange – Exterior – Silver ARE designed to replace traditional expansion anchors

Timco micro plating (Nano) technology gives a higher resistance to corrosion

High-Low parallel threads for ease of insertion and high pull-out values

Removable & adjustable non-expansion through fixing

Unique concave thread configuration

BS7671:2018 IET Wiring Regulations (Eighteenth edition)

Technical Data:

Concrete ≥25N/mm2

Drill Hole Ø (mm) 8.0
Min. Embed. Depth (mm) 40
Min. Drill Hole Depth (mm) 55
Deeper Embed. Depth (mm) 60
Rec. Tensile Load (kg) – Min. Embed. Depth 3.93
Rec. Tensile Load (kg) – Deeper Embed. Depth 8.36
Min. Over-Drill for Dust (mm) 15
Min. Centre Spacing (mm) 120
Min. Edge Distance (mm) 60
Min. Structure Thickness (mm) 90
Max. Rec. Load (kg) – Min. Embed. Depth 393
Max. Rec. Load (kg) – Deeper Embed. Depth 836

Fletton Brick 30N/mm2
Drill Hole Ø (mm) 8.0
Min. Embed. Depth (mm) 40
Min. Drill Hole Depth (mm) 55
Rec. Tensile Load (kN) 2.68
Max. Rec. Load (kg) 268
Min. Over-Drill for Dust (mm) 15
Min. Centre Spacing (mm) –
Min. Edge Distance (mm) –
Min. Structure Thickness (mm) –

Cheshire Brick 45N/mm2
Drill Hole Ø (mm) 8.0
Min. Embed. Depth (mm) 40
Min. Drill Hole Depth (mm) 55
Rec. Tensile Load (kN) 2.19
Max. Rec. Load (kg) 219
Min. Over-Drill for Dust (mm) 15
Min. Centre Spacing (mm) –
Min. Edge Distance (mm) –
Min. Structure Thickness (mm) –

Class B Eng. Brick 75N/mm
Min. Embed. Depth (mm) 40
Min. Drill Hole Depth (mm) 55
Rec. Tensile Load (kN) 4.33
Max. Rec. Load (kg) 433
Min. Over-Drill for Dust (mm) 15
Min. Centre Spacing (mm) –
Min. Edge Distance (mm) –
Min. Structure Thickness (mm) –

Applications:
Masonry fixings, concrete fixings, concrete block work, brick work, thunder bolts.
